$0.00
Compact 1×1 SFP+ cage kit featuring a black pull-link for quick, positive transceiver handling. Zinc-alloy cage hardware delivers strong EMI shielding; SUS304 springs and screws keep the latch precise over time. A TPU tail sleeve improves cable routing and user feel. The complete kit installs with through-hole anchors for rugged ground integrity and vibration resistance. RoHS/REACH compliant and SFP+ compatible, it’s an easy choice for 10G switches, routers, and NIC designs.
Key Features at a Glance
Single-port SFP+ cage with positive black pull-link
Thru-hole anchoring for strong retention and grounding
Zinc-alloy base & cover for EMI shielding
SUS304 stainless springs & screws for long life
TPU tail sleeve for clean cable support
Fast, complete kit—no extra hardware needed
RoHS/REACH compliant; 10G SFP+ form-factor
Highlights
Rugged, EMI-shielded cage with a reliable pull-link latch and complete hardware set—built for high-cycle hot-plug SFP+ ports.
Applications
SFP/SFP+ optical modules • Ethernet switches/routers • Server NICs • Storage and telecom/datacom line cards
SFP plus 1×1 cage kit with black pull-link for securing hot-pluggable SFP+ optical transceivers in switches, routers, and NICs. The assembly combines a zinc-alloy base and upper cover for robust EMI shielding with a positive-latching pull-link for confident insertion and extraction. Springs and screws in SUS304 stainless steel maintain consistent latch force over long service life, while a TPU tail sleeve supports cable management and front-panel ergonomics.
| GENERAL | |||
| Status | Active | Category | High-Speed EMI Cages |
| Part Number | DW-SFP-0032-01 | Description | SFP Cage Assembly Kit with Pull-link, Upper Cover, Spring & Tail Sleeve |
| Application | Module-to-Board | Component Type | Cage Assembly |
| Product Name | SFP Cage Assembly | Sealable | Yes |
| Keywords | SFP Cage, External Connector | Features | SFP cage with pull tab and tail sleeve |
| Thermal Accessory Type Included | None | Lightpipe Style | Not Applicable |
| Number of Ports | 1 × 1 | _ | _ |
| ELECTRICAL | |||
| Data Rate | _ | _ | _ |
| Not applicable (Mechanical Assembly Kit) | _ | _ | _ |
| PHYSICAL | |||
| EMI shielding | Full Metal Enclosure (Zinc + SUS304) | Pluggable I/O Applications | SFP |
| Cage Material | 3# Zinc Alloy, SUS304 Steel, TPU | Orientation | Horizontal |
| Packaging Type | Kit with multiple components | Termination Interface Style | Mechanical Mounting |
| Rear Legs | None | Thermal Solutions | None |
| Thermal Height | N/A | Circuit Application | Mechanical Retention Only |
| Included Lightpipe | No | Light Pipes per Port | 0 |
| Heat Sink Compatible | No | Tail Length | N/A |
| Operating Temperature Range | 55~85°C (based on material spec) | PCB Thickness (Recommended) | N/A |
