1×1 SFP+ Cage Kit with Blue TPV Pull-Link – Designed with a durable TPV pull-link in blue for fast identification and easy hot-swap handling the unit supports effortless transceiver installation and removal. The base and upper cover, both made from 3M zinc-plated alloy, deliver excellent electromagnetic shielding and long-term durability. A SUS304 stainless-steel spring and screw set maintains optimal compression force and vibration resistance, preventing module loosening during operation.
• Applications: 10G SFP+ optical transceivers, telecom and Ethernet switch equipment, hot-pluggable NIC transceiver bays, high-density networking hardware.
• Highlights: Blue TPV pull-handle for quick identification and tool-less removal; zinc-plated shell for EMI protection; SUS304 spring & screws for securecompression and vibration resistance; designed for hot-swappable 10G SFP+ modules; RoHS / REACH / Low-Halogen compliant.
1×1 SFP+ cage kit engineered for compact optical transceiver integration in high-speed networking and telecommunication systems. This single-port cage assembly combines mechanical precision and EMI protection, ensuring stable performance for 10G SFP+ applications.
| GENERAL | |||
| Status | Active | Category | High-Speed EMI Cages |
| Part Number | DW-SFP-0073-01 | Description | SFP Cage Assembly Kit with Pull-link, Upper Cover, Spring & Screws |
| Application | Module-to-Board | Component Type | Cage Assembly |
| Product Name | SFP Cage Assembly | Sealable | Yes |
| Keywords | SFP Cage, External Connector | Features | SFP cage with blue pull tab |
| Thermal Accessory Type Included | None | Lightpipe Style | Not Applicable |
| Number of Ports | 1 × 1 | ||
| ELECTRICAL | |||
| Data Rate | _ | _ | _ |
| Not applicable (Mechanical Assembly Kit) | _ | _ | _ |
| PHYSICAL | |||
| EMI shielding | Full Metal Enclosure (Zinc alloy + SUS304) | Pluggable I/O Applications | SFP |
| Cage Material | 3# Zinc Alloy, SUS304 Steel | Orientation | Horizontal |
| Packaging Type | Kit with multiple components | Termination Interface Style | Mechanical Mounting |
| Rear Legs | None | Thermal Solutions | None |
| Thermal Height | N/A | Circuit Application | Mechanical Retention Only |
| Included Lightpipe | No | Light Pipes per Port | 0 |
| Heat Sink Compatible | No | Tail Length | N/A |
| Operating Temperature Range | 55~85°C (based on material spec) | PCB Thickness (Recommended) | N/A |
