RJ45 8 port 8P8C connector with LED tab-up for high-density PCB Ethernet applications, designed with an 8-port modular jack structure, tab-up orientation, and integrated LED indicators for port status display. Based on the drawing, this connector supports 125 VAC RMS, 1.5A current rating, and uses gold-plated contacts over nickel with a nickel-plated shell for reliable multi-port network connection.
• Applications: Ethernet switches, routers, communication equipment, industrial control systems, embedded network boards, LAN interface modules, network appliances, automation devices.
• Highlights: RJ45 8 port connector; 8P8C modular jack; integrated LED indicators; tab-up type; 125 VAC RMS voltage rating; 1.5A current rating; 50mΩ max contact resistance; 500MΩ min insulation resistance; 1000V AC withstand; 750 mating cycles minimum; RoHS compliant.
RJ45 8 port 8P8C connector with LED tab-up is a multi-port Ethernet connector designed for high-density PCB network interface applications in switches, routers, communication equipment, and industrial control systems. Based on the drawing, this product is an 8-port RJ45 modular jack assembly with 8P8C contact structure, tab-up orientation, and integrated LED indicators on each port. The recommended PCB layout in the drawing is arranged for an 8-port jack top view, supporting compact board design for multi-port LAN applications.
This RJ45 8 port 8P8C connector with LED tab-up is designed for dependable electrical and mechanical performance in board-level Ethernet interface systems. According to the specification section in the drawing, it has a voltage rating of 125 VAC RMS and a current rating of 1.5A. The drawing also specifies contact resistance of 50mΩ max, insulation resistance of 500MΩ min at 500V DC, and dielectric withstanding voltage of 1000V AC 50Hz for 1 minute. These specifications support stable contact performance and insulation reliability in networking equipment.
The LED configuration chart in the drawing shows multiple LED options for the series, including versions with LED1 yellow / LED2 yellow, LED1 yellow / LED2 green, LED1 green / LED2 yellow, and LED1 green / LED2 without LED. With its 8-port shielded structure, tab-up layout, and integrated LED indication, this RJ45 connector is suitable for networking switches, communication terminals, embedded networking boards, and industrial Ethernet products. The drawing also confirms RoHS compliance.
| General | |||
| Status | Active | Category | Modular Jack |
| Part Number | DW-RJ45-D008160-XXTP-XX | Description | RJ45 Ganged Jack, 8-Port, 8P8C, With LED, Shielded, Tab-Up |
| Product Name | 8-Port RJ45 8P8C LED Jack | Magnetic | No |
| Component Type | Receptacle | Power over Ethernet (PoE) | N/A |
| Type | Modular Jack | Packaging | Tray Packing |
| Width | 126.75 ±0.5 mm | Height | 13.20 ±0.25 mm |
| Length | 15.75 ±0.35 mm | Installed Height | 13.20 ±0.25 mm |
| Housing Material | PA46, UL94V-0, Black | Contact Material | 0.46 mm Phosphor Bronze |
| Contact Plating | Gold Plating over Nickel (exact XX plating code varies) | Shield Material | C2680-H, t=0.20 mm |
| Shield Plating | Nickel Plated, 30–80u” | Country of Origin | — |
| Electrical | |||
| Current – Maximum per Contact | 1.5 AMP | Grounding to Panel | — |
| Grounding to PCB | Yes | Shielded | Yes |
| Voltage – Maximum | 125 VAC RMS | Operating Temperature | -40°C to +85°C |
| Contact Resistance (Max) | 50 mΩ Max | Storage Temperature | -40°C to +85°C |
| Insulation Resistance (Min) | 500 MΩ Min @ 500V DC | EMI | Yes |
| Dielectric Strength | 1000 VAC, 50Hz, 1 Minute | Lead-Free Process Capability | Wave Soldering Temp. 235°C ±5°C |
| RoHS | Yes | Customs Tariff Number | — |
| Physical | |||
| Color – Housing | Black | Orientation 方向 | Side Entry Right Angle |
| Positions / Loaded Contacts | 8P8C per Port | Lightpipes / LEDs | Yes, LED1 + LED2 per port |
| Port Configuration | 8×1 Ganged | Termination Interface | DIP / THT |
| Durability (mating cycles min) | 750 Cycles Min | Inverted / Top Latch | Yes |
| Jack Height | 13.20 ±0.25 mm | Latch / Tab Orientation | Tab-Up |
| Material – Resin | PA46 UL94V-0 | Material – Metal | Phosphor Bronze / Shield C2680-H |
| PCB Retention | Yes | Pitch – Mating Interface | 1.02 ±0.10 mm |
| Pitch – Termination Interface | 1.02 ±0.10 mm | PCB Thickness – Recommended | — |
| Single Port Pitch | 15.75 ±0.25 mm | PCB Layout Pitch | 15.75 ±0.10 mm |
| Recommended PCB Layout Overall | 126.50 mm | Inner PCB Layout Length | 122.95 ±0.15 mm |
| LED Configuration | Series code dependent | Net Weight | — |
