Product Short Description
The SFP+ cage kit with pull link and TPU sleeve is a compact, matte nickel-plated single-port SFP+ cage assembly that combines a spring-loaded pull-link, flexible TPU tail sleeve and SUS304 springs to deliver secure hot-swapping, EMI shielding and cable protection for 10G optical modules.
Applications:
SFP+ optical modules (10GBase-SR/LR)
Network interface cards and line cards
Data center optical switches and aggregation platforms
High-speed telecom transceivers and access equipment
Highlights:
SFP+ cage kit with pull link and TPU sleeve for secure, strain-relieved connections
Matte nickel-plated 3M zinc cage housing for robust EMI protection
Spring-loaded pull-link mechanism for reliable hot-swapping of SFP+ modules
TPU tail sleeve minimizes cable bend and exit stress
SUS304 springs and screws ensure stable retention and grounding
Fully RoHS, REACH SVHC and low-halogen compliant for carrier-grade deployments
SFP+ cage kit with pull link and TPU sleeve is a precision-engineered single-port SFP+ cage assembly designed for high-performance optical module integration in modern networking hardware. This SFP+ cage kit with pull link and TPU sleeve combines a compact mechanical envelope with secure retention, cable strain relief and dependable EMI shielding, making it ideal for 10Gbps SFP+ links in switches, routers and data center platforms.
The core housing consists of a 3M zinc alloy upper and lower cage finished with matte nickel plating to deliver strong electromagnetic shielding and stable grounding at high data rates. A spring-loaded pull-link mechanism, also based on zinc components, enables secure insertion and smooth, tool-free extraction of SFP+ transceivers, supporting frequent hot-swap operations in service environments.
| GENERAL | |||
| Status | Active | Category | SFP Plug Assembly Kit with Spring, Pull-Link, Tail Sleeve, and Upper/Lower Covers |
| Part Number | DW-SFP-0245-01 | Description | SFP plug kit including spring-loaded dual shell, screw set, and pull mechanism |
| Application | Module-to-Board | Component Type | Mechanical Assembly Kit |
| Product Name | SFP Plug Assembly | Sealable | Yes |
| Keywords | SFP Optical module, External Connector, SFP Cage | Features | Dual-spring shell with integrated pull tab and retention system |
| Thermal Accessory Type Included | None | Lightpipe Style | Not Applicable |
| Number of Ports | 1 × 1 | ||
| ELECTRICAL | |||
| Data Rate | _ | _ | _ |
| Not applicable (Mechanical Assembly Kit) | _ | _ | _ |
| PHYSICAL | |||
| EMI shielding | Full Metal Enclosure (Zinc alloy + SUS304) | Pluggable I/O Applications | SFP |
| Cage Material | 3# Zinc Alloy, SUS304 Steel, TPU | Orientation | Horizontal |
| Packaging Type | Kit with multiple components | Termination Interface Style | Mechanical Mounting |
| Rear Legs | None | Circuit Application | Mechanical Retention Only |
| Thermal Height | N/A | Light Pipes per Port | 0 |
| Included Lightpipe | No | Tail Length | N/A |
| Heat Sink Compatible | No | PCB Thickness (Recommended) | N/A |
| Operating Temperature Range | 55~85°C (based on material spec) |
